Brew-tiful Night at Brisbane Brew & Learn!
Rounding up another successful Brew & Learn event for BuildingPoint.
Rounding up another successful Brew & Learn event for BuildingPoint.
Over the years, the BPA team has hosted and participated in some outstanding events, from SketchUp BIZ Camps and Tekla Techme conferences to Trimble Dimensions. However, one of our favourites must be our very own Brew and Learn series, which we’re proud to host at locations across Australia.
Recently, the BuildingPoint Brisbane team had the pleasure of hosting another Brew and Learn night—complete with burgers, cold beers, and plenty of networking. Amid the lively conversations and great atmosphere, we even managed to squeeze in some valuable learning!
In this post, we will walk you through the Trimble Connect Construction digital workflow we discussed during the event. The evening was hosted by Andrew Farley, General Manager of Sales and Marketing, alongside Jason Carpenter, Construction Segment Manager; Tom Malloy, Structures Segment Manager; Liam Dixon, Field Solutions Technical Account Manager; Hector Sarmiento, SketchUp’s Technical Account Manager; Brett Holland, Tekla Account Manager, Fabrication; and Robert Lamb, Tekla Account Manager.
During our recent Brew and Learn session, the team demonstrated how Trimble’s integrated workflow streamlines construction processes. Let me illustrate this through a creative scenario: imagine the brewery needs to extend its gym on the upper floor. Here’s how Trimble’s advanced solutions would simplify this project.
The project kicks off with FieldLink, where the construction team uses the X9 scanner to accurately capture precise site measurements, focusing on the brewery’s existing structure. Specifically, these measurements include detailed data on walls, floor layouts, and any potential constraints for the new gym. Moreover, the data is immediately transmitted via Trimble Connect to the Trimble Reality Capture Platform Service (TRCPS).
Next, using Trimble Connect and TRCPS, the data from the laser scans and UAV imagery is processed into detailed point clouds and 360-degree imagery, providing the design team with an accurate 3D representation of the brewery’s upper floor. In addition, the cloud-based platform ensures secure data sharing, allowing stakeholders such as architects, builders and engineers to collaborate on the captured data in real time.
Once the field data is ready, the design phase begins. First, the 3D model is imported into SketchUp through Scan Essentials for conceptual design of the gym extension. Then, for the structural aspects, the model is passed to Tekla Structures and Tedds, where engineers perform structural analysis and create detailed 3D models. Importantly, the seamless integration between these platforms using Trimble Connect ensures that the design aligns perfectly with the original field data.
Following that, the team brings the digital model back to the field using Augmented Reality (AR). With Connect AR capabilities, the construction team can visualise the gym extension as it would appear in real life, overlaid on the existing brewery structure. This approach ensures the designs are accurate and that potential clashes are identified before construction begins, reducing the chances of rework.
The Trimble Ri robotic total station facilitates precise digital Setout by transforming 3D designs into real-world placements. Specifically, design files are uploaded to the FieldLink on the Trimble Ri tablet, which connects to control points on-site to situate the model correctly for accurate Setout. As the team sets out each element, the Ri provides real-time feedback, ensuring accurate alignment with the digital model. Consequently, this automation boosts accuracy, reduces human error, and accelerates the Setout process, helping to keep the project on time and within budget.
Finally, the last step is an as-built check to confirm that the completed project matches the original design. Using the X9 scanner, the team captures post-construction as-built data of the gym extension. These measurements are compared to the initial design to identify any deviations. This ensures quality control and produces as-built documentation for future maintenance, reinforcing client confidence in the project’s execution.
At BuildingPoint, we understand that true connection with customers goes beyond phone calls and video chats. In fact, events like Brew and Learn give us invaluable insights into how Trimble technology can solve specific challenges in your industry—whether you’re in construction, architecture, or steel fabrication. Through these conversations we can fine-tune our solutions, making your workflows more efficient and cost-effective.
Furthermore, our support doesn’t end there. From IDEA StatiCa to Tekla and SketchUp, our local team provides comprehensive product support. Ultimately we are committed to being a trusted partner you can rely on.
Looking ahead, the BuildingPoint team, along with our technology partners, is dedicated to pushing the boundaries of construction technology. We’re excited by the possibilities, and we remain committed to driving innovation, delivering exceptional support, and ensuring the success of our customers.
Moreover, at BuildingPoint Australia, our focus on industry involvement, unmatched customer support, and deep technical expertise serves as the backbone of our business. We’re proud to empower our clients to navigate the complexities of construction with confidence. Together, we’re paving the way for a more efficient and innovative future for the industry.
If this workflow interests you or your business, please feel free to contact our friendly sales team at any time via: Contact Us – BuildingPoint Australia
